Digital Torque Adapter With Tire Gauge

KA-1621TP(2)
KA-1621TP(2)
KA-1621TP(1)

Model

KA-1621TP / KA-1683TP

Specification:

  • Digital torque value reading
  • Target torque value setting
  • 50 memory record
  • Track and Peak hold mode
  • Alarm: LED light bar and buzzer
  • Powered by 2 x AAA batteries
  • 5 unit set (Nm. Lb-ft. In-ft.kg-m, Kg-cm)
  • Auto shut off: 60 seconds (if do not use digital torque adapter)
  • U.S / Taiwan Patented
ADD INQUIRY

  KA-1621TP KA-1683TP
Dr 1/2” 3/8”
Accuracy +/-2% +/-2%
Torque Range 40-200Nm(29.5-147.6lb-ft) 27-135Nm(19.9-99.67lb-ft)
Pressure Range 1-100PSI 1-100PSI
Resolution 0.1Nm (0.1lb-ft) /0.1PSI 0.1Nm (0.1lb-ft) /0.1PSI
Preset 1 1
Pressure Unit PSI, Kpa, Bar, Kg-cm PSI, Kpa, Bar, Kg-cm
Length 75mm 75mm
Weight 190gs 190gs
Operating ambient temperature -10ºC-60 ºC ºF-139.9 ºF) -10ºC-60 ºC ºF-139.9 ºF)
Storage temperature -20 ºC -70 ºC (-4 ºF-57.9 ºF) -20 ºC -70 ºC (-4 ºF-57.9 ºF)
Operating relative humidity 15-90% noncondensing 15-90% noncondensing
