Description
|
|
1. SETTING Confirm the remover direction regarding to the direction indication. ![]() |
2. REMOVER ATTACHMENT Attach the remover to the plastic clamp. ![]() |
||
3. RELEASING CLAMP LOCK Push the remover with thumbs then the clamp lock becomes released. ![]() |
|||
4. CLAMP SEPARATION Pull the remover to separate the plastic clamp and tubes. ![]() |
5. REMOVER PULL OUT Operate the stopper lever and pull out the remover from A/C tubes. ![]() |
6. CLAMP REMOVAL Pull out the plastic clamp from the remover. ![]() |
Cautions:
- Refrigerant must be evacuated before using the remover.
- Removing the plastic clamp filled with refrigerant may cause frostbite and eye blind.
- Remover must be keep away from engine coolant and battery electrolyte.
Deformation of needles may cause the difficult operation for releasing the clamp lock.
